General Information

Product Type: IP CCTV Camera

PCB Board-  PA4 Board

Application: 5MP Network IP Camera Module

Technology: Digital IP Surveillance

Image Sensor

Resolution: 5 Megapixel

Sensor Type: CMOS Image Sensor

Frame Rate: Up to 20fps @5MP / 25fps @4MP

Video Compression

Supported Formats: H.265 / H.264 / MJPEG

Dual Stream Support: Yes

Bitrate Control: CBR / VBR

Lens Support

Lens Type: 10081 Ytot Lens Compatible

Supported Lens: 2.8mm / 3.6mm / 6mm Options

IR Cut Filter Support: Yes

Network Features

Protocol Support: TCP/IP, HTTP, RTSP, ONVIF

ONVIF Compatibility: Yes

Remote Viewing: Mobile App + CMS Software

Audio Support

Mic Input: Supported (Optional)

Smart Features

Motion Detection

Email Alert / Push Notification

Night Vision IR Control Support

Night Full colour Dual LED

OSD Menu Control

Interface & Connectivity

Ethernet Port: RJ45 10/100 Mbps

Power Input: DC 12V

IR LED Board Connector: Yes

Alarm I/O: Optional Support

SD Card Slot: Optional (Depends on Version)

PCB Board Features

Board Type: Main Camera Module PCB

Chipset Support: HiSilicon / XM / Goke (Depends on Variant)

Usage: Bullet / Dome / PT Camera Assembly

Operating Conditions

Working Temperature: -10°C to +60°C

Humidity: ≤95% Non-Condensing

Package Includes

5MP PA4 IP Camera PCB Board

Sensor Module Attached

Connector Pins (As per Model)
